Adding remotes, scene controllers as entities to MSR

Andr

Many thanks!
will be digging in to this later tonight again.

A few follow up questions to check that I understand things correctly.

capabilities: ['button']

In frase above, somewhere in MSR code, the word 'button' is equal to what I tried to specify with this section and that why that was unnecessary?
```
attributes:

         state:

           type: string

           values:

             - 'single'

             - 'double'

             - 'triple'

             - 'hold'

             - 'release'

         since:

           type: int, timestamp


About how to fill the 'form' row, in your example you use

from: "event.data.payload.action"


And I assume that this comes from this marked words?
![b80fc4eb-315e-4ba0-af3b-ffe5f470ebc6-image.png](/assets/uploads/files/1656701263037-b80fc4eb-315e-4ba0-af3b-ffe5f470ebc6-image.png)

I starting to think that yaml file should be read somewhat like a folder tree, would that make sense?
So, in your example, if the 'start action' was like a .bat-file the way to think about the Form row the adress would be **event\data\payload\action**
Please say I am on the right track 😂🙏

Andr

Sorry for the messy post above, writing from my phone

toggledbits

Yeah, you need to fix it. It should not be left like this, as the discussion may be read by others in future, and I can't follow it (also on my phone), and likely nobody would bother

From what I can see, I don't know why you're stuck on using payload in your from value, that word/key does not appear in your event data.

Andr

Ok, for some reason i can't make the mess go away in earlier post, so double post...

Many thanks!
will be digging in to this later tonight again.

A few follow up questions to check that I understand things correctly.

capabilities: ['button']

In frase above, somewhere in MSR code, the word 'button' is equal to what I tried to specify with this section and that why that was unnecessary?

attributes:

            state:

              type: string

              values:

                - 'single'

                - 'double'

                - 'triple'

                - 'hold'

                - 'release'

            since:

              type: int, timestamp

About how to fill the 'form' row, in your example you use

from: "event.data.payload.action"

And I assume that this comes from this marked words?

I starting to think that yaml file should be read somewhat like a folder tree, would that make sense?
So, in your example, if the 'start action' was like a .bat-file the way to think about the Form row the adress would be event\data\payload\action
Please say I am on the right track

Andr

Ok, some progress thanks to @toggledbits of course.

Copied in his code in reactor.yaml and that worked fine of course. Also added a line for 3x click and that worked also.

event_targets:    # this section starts the event-receiving entities
        "Keyfob_fyrkant":      # Assign an ID to your entity; each entity must have a unique ID
          name: Lukas Keyfob Fyrkant   # This is optional but recommended, so you have a friendly name
          capabilities: ['button']  # define an array of capabilities to be modified by the event
          events:  # define an array of events that modify capability attributes on the entity
            - event:  # start of an event; each element of the events array begins this way
                event_type: zwave_js_value_notification
                data:  # optional section, if further matching to the event data is required
                  node_id: 15
                  property: "scene" # Square button
                  property_key: "001"
              response:  # begin the (required) response section for handling the event
                "button.state":  # an attribute that the event modifies.
                  from: "event.data.value"  # dot-reference expression to pull value from event message
                  map:                    # optional, map to modify value
                    KeyPressed: 'single'   # if value is value_in, it is mapped to new_value
                    KeyPressed2x: 'double'
                    KeyPressed3x: 'tripple'

But, still, I can't for some reason really understand the code and how different parts relate to each other.

In 'event data' I was expecting to fill out in the 'label' field from hass_event log because that is an uniq value for each one of the six buttons, and then the 'value' field that identifies the number of keypresses on this specific button.
In my mind that would give a uniq combination for MSR to identify.
I did (with very low hopes) tried it also

event_targets:    # this section starts the event-receiving entities
        "Keyfob_fyrkant":      # Assign an ID to your entity; each entity must have a unique ID
          name: Lukas Keyfob Fyrkant   # This is optional but recommended, so you have a friendly name
          capabilities: ['button']  # define an array of capabilities to be modified by the event
          events:  # define an array of events that modify capability attributes on the entity
            - event:  # start of an event; each element of the events array begins this way
                event_type: zwave_js_value_notification
                data:  # optional section, if further matching to the event data is required
                  node_id: 15
                  label: "Scene 001" # Square button
                  value: "KeyPressed"
                  value: "KeyPressed2x"
                  value: "KeyPressed3x"
              response:  # begin the (required) response section for handling the event
                "button.state":  # an attribute that the event modifies.
                  from: "event.data.value"  # dot-reference expression to pull value from event message
                  map:                    # optional, map to modify value
                    KeyPressed: 'single'   # if value is value_in, it is mapped to new_value
                    KeyPressed2x: 'double'
                    KeyPressed3x: 'tripple'

and of course:
Reactor did not start.

I would really like to get a grip why this is what is needed in event data

                  property: "scene" # Square button
                  property_key: "001"

Meanwhile, as @toggledbits code of course worked I did the simplest rule with an action, toggle a lamp on off.

Here I expected (or hoped) to find triggers for every combination of button presses.
For now Square: 1x, 2x, 3x
But I guess I need to set the 'button.state' to 'contains' 'single' 'double' etc.
But whatever event state MSR caught, it doesn't resest.
When MSR start the value is NULL, but after a click it holds that value, for example 'single', and I expect it to reset immediately after the 'single' event have passed by.

So, this is it for today. It is friday night and I am happy to say that I think my wife misses me
Have a great weekend everyone.

toggledbits

But, still, I can't for some reason really understand the code and how different parts relate to each other.

The event section is a filter to look for a specific event. In your version, you have multiple value keys, which is not allowed. Also, you don't want to filter by value, just accept them all and let the response section deal with them. I recommended against using label because it's changeable in ZWave, whereas the property and property_key values are defined by the device and will not change.

So again, the event section is the filter that determines what incoming event will match, and what will not.

Once an event matches, the response section determines what to do with it. Each component of the response section is an attribute of an assigned capability and the instructions to set it. In the case of button.state, my version says grab the value from event.data.value, and then, map that value from the device's string to one of Reactor's accepted capability/attribute value. Setting button.since completes the "contract" of the button capability (i.e. makes it work like similar uses of button in other devices and related to other controllers). I'm not sure I can explain it more simply than that.

It's really just a "if you find this... do this" configuration. The effect is that if a matching button event is detected by the event section, the response section will interpet the value and map it to a Reactor-compatible value to place on the entity attribute button.state, and also update the button.since timestamp. Thus the since timestamp changes every time a button press event is received, but state may not change, because it's possible to press a button once, wait 15 seconds, and press the same button again, which will result in the value single being persistent on the state attribute and not changing. So to detect an event, you have to check both state and since (and this is consistent with all button behavior in Reactor).

To test button state in a rule, you test button.state for what you want in that rule (equals single, double, triple), and you AND that test with a button.since changes (from any to any). That will send a very short pulse when a matching button press occurs. While testing, to make sure you can see it, add a "sustained for" delay on the changes condition of a few seconds (keep it short), and you'll more easily see what's going on in the status view. Make sure to remove the delay when you're done playing (keeping it will dampen response to buttons when, for example, a single press is done repeatedly within the delay period).

Example here: https://smarthome.community/assets/uploads/files/1646184651741-cbff18f3-ce2d-4ecd-ae65-2554f77a4a80-image.png

Andr

@toggledbits

Ok, I understood it at first that I needed to specify more stuff in the event section, like 'value' so it then could be mapped to right command, otherwise it would not be known.

But nodeid, property and property key is just to filter out right device, all the other data is still there?
And in that case, I guess that it would work to skip event data and just mapping commands to MSR functions? (Of course nothing else can send 'Keypressed' command because that would be messy)

toggledbits

@andr said in Adding remotes, scene controllers as entities to MSR:

But nodeid, property and property key is just to filter out right device, all the other data is still there?

That's right. The event section only filters using the data; it does not modify the data or transform it in any way. Whatever is received in the event structure stays as received.

@andr said in Adding remotes, scene controllers as entities to MSR:

And in that case, I guess that it would work to skip event data and just mapping commands to MSR functions?

I'm not sure what you mean by this. I don't think you want to skip anything. You should filter the incoming events, to make sure that you are handling the right events from the right device. So you need to be specific in the event filter to both the event type and the sending device.

Andr

@toggledbits said in Adding remotes, scene controllers as entities to MSR:

||@andr said in Adding remotes, scene controllers as entities to MSR:

And in that case, I guess that it would work to skip event data and just mapping commands to MSR functions?||

I'm not sure what you mean by this. I don't think you want to skip anything. You should filter the incoming events, to make sure that you are handling the right events from the right device. So you need to be specific in the event filter to both the event type and the sending device.

That was just me trying to understand how stuff is related, not something I would try out.
For example, in my system there is only one device that are sending "Keypressed3x" and that can not be mixed up with anything else. In that case if I had such uniq string to map to MSR command 'triple' I could skip the filtering in event section?

Again, this is just for my own curiosa trying to learn something new.

Andr

Anyway, some kinds of sucess the last nights

All buttons are configured and seems to work so far.

The final reactor.yaml looks like this (just showing the first two buttons as it is just the entity name and 'property key' that differ )

event_targets:    # this section starts the event-receiving entities
        "Keyfob_Fyrkant":      # Assign an ID to your entity; each entity must have a unique ID
          name: Lukas Keyfob Fyrkant   # This is optional but recommended, so you have a friendly name
          capabilities: ['button']  # define an array of capabilities to be modified by the event
          events:  # define an array of events that modify capability attributes on the entity
            - event:  # start of an event; each element of the events array begins this way
                event_type: zwave_js_value_notification
                data:  # optional section, if further matching to the event data is required
                  node_id: 15
                  property: "scene" # Square button
                  property_key: "001"
              response:  # begin the (required) response section for handling the event
                "button.state":  # an attribute that the event modifies.
                  from: "event.data.value"  # dot-reference expression to pull value from event message
                  map:                    # optional, map to modify value
                    KeyPressed: 'single'   # if value is value_in, it is mapped to new_value
                    KeyPressed2x: 'double'
                    KeyPressed3x: 'tripple'
                    KeyHeldDown: 'hold'
                    KeyReleased: 'release'
                "button.since":  # an attribute that the event modifies.
                  from: "event.context.id"  # dot-reference expression to pull value from event message
        "Keyfob_Ring":      # Assign an ID to your entity; each entity must have a unique ID
          name: Lukas Keyfob Ring   # This is optional but recommended, so you have a friendly name
          capabilities: ['button']  # define an array of capabilities to be modified by the event
          events:  # define an array of events that modify capability attributes on the entity
            - event:  # start of an event; each element of the events array begins this way
                event_type: zwave_js_value_notification
                data:  # optional section, if further matching to the event data is required
                  node_id: 15
                  property: "scene" # Circle button
                  property_key: "002"
              response:  # begin the (required) response section for handling the event
                "button.state":  # an attribute that the event modifies.
                  from: "event.data.value"  # dot-reference expression to pull value from event message
                  map:                    # optional, map to modify value
                    KeyPressed: 'single'   # if value is value_in, it is mapped to new_value
                    KeyPressed2x: 'double'
                    KeyPressed3x: 'triple'
                    KeyHeldDown: 'hold'
                    KeyReleased: 'release'
                "button.since":  # an attribute that the event modifies.
                  from: "event.context.id"  # dot-reference expression to pull value from event message

A thought that crossed my mind recently, to maybe expand the functions of this little remote in the future.
Fibaro have built in a possibilty for 6 extra scenes that activates after a sequence of button presses I specify. I have not activated this yet as I don't think I really need it, but what I realised is that it probably quite easy to add a lot of differnt button sequences in MSR as long or short that I want?

Next part is to get some rules and actions set-up that can use the remote.

Andr

Seems to work like a charm

Started out with a few rules to let him control a Sonos in his room.
This one is for starting his favorite playlist, when it not is bedtime and that playlist isn't already playing.

christian_fabre

Thanks ...
I followed this post and managed to successfully use my HANK SCN04 remote with Reactor and Home Assistant.

Andr

@christian_fabre
Happy to hear that it come to use (and that myself learned a few things on the way)

toggledbits

@andr said in Adding remotes, scene controllers as entities to MSR:

In that case if I had such uniq string to map to MSR command 'triple' I could skip the filtering in event section?

No. You must filter. If you don't, every incoming event then causes the response section to act and will likely cause spurious changes of the entity data.

apocalypsehobby

@christian_fabre said in Adding remotes, scene controllers as entities to MSR:

Thanks ...
I followed this post and managed to successfully use my HANK SCN04 remote with Reactor and Home Assistant.

@christian_fabre Do you mind sharing the code you used? I have two of the HANK SCN04 as well, and am trying to do the same thing

toggledbits

I believe that the following is a cleaned-up version of the final code (that which @Andr posted above is not indented properly as shown in these forums and won't work directly, so please use this instead):

controllers:
  - id: hass
    implementation: HassController
    enabled: true
    name: Home Assistant
    config:
      source: 'ws://192.168.0.nnn:8123'
      # The lines above are a guide for indenting only, DO NOT COPY.
      # --- Start copy/paste from below this line ---
      event_targets:
        "hank_XXX_btn_1":
          name: "Hank XXX Button 1"
          capabilities:
            - button
          events:
            - event:
                event_type: zwave_js_value_notification
                data:
                  node_id: XXX  # Put your ZWaveJS node ID here
                  property: scene
                  property_key: "001"  #  001=button 1, 002=button 2, etc.
              response:
                button.since:
                  from: event.context.id
                button.state:
                  from: event.data.value
                  map:
                    KeyHeldDown: hold
                    KeyPressed: single
                    KeyPressed2x: double
                    KeyPressed3x: triple
                    KeyReleased: release
        "hank_XXX_btn_2":
          name: "Hank XXX Button 2"
          capabilities:
            - button
          events:
            - event:
                event_type: zwave_js_value_notification
                data:
                  node_id: XXX  # Put your ZWaveJS node ID here
                  property: scene
                  property_key: "002"  #  001=button 1, 002=button 2, etc.
              response:
                button.since:
                  from: event.context.id
                button.state:
                  from: event.data.value
                  map:
                    KeyHeldDown: hold
                    KeyPressed: single
                    KeyPressed2x: double
                    KeyPressed3x: triple
                    KeyReleased: release

You need to copy the lines beginning with event_targets: to the end, and paste them into the config section of the controllers entry for your HassController instance. You should change all instances of XXX to the ZWave node ID of your Hank controller. This will give you buttons 1 and 2. To add buttons 3 and 4, just copy-paste either button 1 or button 2 and modify the button number (property_key), entity name, and entity ID. One Reactor entity is created for each button you configure.

If you are not well-versed in editing YAML, I suggest you make a backup copy of your config directory before making any changes.

christian_fabre

# If you have more than one of any type of controller, just copy the section for controller type
# and give it new (unique) "id". There is no limit on the number of controllers.
controllers:

  - id: hass
    enabled: true
    implementation: HassController
    name: A Home Assistant system
    config:
      source: 'wss://XX.XX.XX.XX:8123'
      access_token: "YYYYYYYYY"
      #
      event_targets:    # this section starts the event-receiving entities
              "Hank_SCN04_bp1":      # Assign an ID to your entity; each entity must have a unique ID
               name: Hank_bp1   # This is optional but recommended, so you have a friendly name
               capabilities: ['button']  # define an array of capabilities to be modified by the event
               events:  # define an array of events that modify capability attributes on the entity
                 - event:  # start of an event; each element of the events array begins this way
                     event_type: zwave_js_value_notification
                     data:  # optional section, if further matching to the event data is required
                       node_id: 12
                       property: "scene" # Square button
                       property_key: "001"
                   response:  # begin the (required) response section for handling the event
                     "button.state":  # an attribute that the event modifies.
                       from: "event.data.value"  # dot-reference expression to pull value from event message
                       map:                    # optional, map to modify value
                         KeyPressed: 'appui_court'   # if value is value_in, it is mapped to new_value
                         KeyReleased: 'appui_relache'
                         KeyHeldDown: 'appui_maintenu'
                     "button.since":  # an attribute that the event modifies.
                       from: "event.context.id"  # dot-reference expression to pull value from event message
              "Hank_SCN04_bp2":      # Assign an ID to your entity; each entity must have a unique ID
               name: Hank_bp2   # This is optional but recommended, so you have a friendly name
               capabilities: ['button']  # define an array of capabilities to be modified by the event
               events:  # define an array of events that modify capability attributes on the entity
                 - event:  # start of an event; each element of the events array begins this way
                     event_type: zwave_js_value_notification
                     data:  # optional section, if further matching to the event data is required
                       node_id: 12
                       property: "scene" # Square button
                       property_key: "002"
                   response:  # begin the (required) response section for handling the event
                     "button.state":  # an attribute that the event modifies.
                       from: "event.data.value"  # dot-reference expression to pull value from event message
                       map:                    # optional, map to modify value
                         KeyPressed: 'appui_court'   # if value is value_in, it is mapped to new_value
                         KeyReleased: 'appui_relache'
                         KeyHeldDown: 'appui_maintenu'
                     "button.since":  # an attribute that the event modifies.
                       from: "event.context.id"  # dot-reference expression to pull value from event message
              "Hank_SCN04_bp3":      # Assign an ID to your entity; each entity must have a unique ID
               name: Hank_bp3   # This is optional but recommended, so you have a friendly name
               capabilities: ['button']  # define an array of capabilities to be modified by the event
               events:  # define an array of events that modify capability attributes on the entity
                 - event:  # start of an event; each element of the events array begins this way
                     event_type: zwave_js_value_notification
                     data:  # optional section, if further matching to the event data is required
                       node_id: 12
                       property: "scene" # Square button
                       property_key: "003"
                   response:  # begin the (required) response section for handling the event
                     "button.state":  # an attribute that the event modifies.
                       from: "event.data.value"  # dot-reference expression to pull value from event message
                       map:                    # optional, map to modify value
                         KeyPressed: 'appui_court'   # if value is value_in, it is mapped to new_value
                         KeyReleased: 'appui_relache'
                         KeyHeldDown: 'appui_maintenu'
                     "button.since":  # an attribute that the event modifies.
                       from: "event.context.id"  # dot-reference expression to pull value from event message
              "Hank_SCN04_bp4":      # Assign an ID to your entity; each entity must have a unique ID
               name: Hank_bp4   # This is optional but recommended, so you have a friendly name
               capabilities: ['button']  # define an array of capabilities to be modified by the event
               events:  # define an array of events that modify capability attributes on the entity
                 - event:  # start of an event; each element of the events array begins this way
                     event_type: zwave_js_value_notification
                     data:  # optional section, if further matching to the event data is required
                       node_id: 12
                       property: "scene" # Square button
                       property_key: "004"
                   response:  # begin the (required) response section for handling the event
                     "button.state":  # an attribute that the event modifies.
                       from: "event.data.value"  # dot-reference expression to pull value from event message
                       map:                    # optional, map to modify value
                         KeyPressed: 'appui_court'   # if value is value_in, it is mapped to new_value
                         KeyReleased: 'appui_relache'
                         KeyHeldDown: 'appui_maintenu'
                     "button.since":  # an attribute that the event modifies.
                       from: "event.context.id"  # dot-reference expression to pull value from event message
      #
      #

I abruptly attach a copy of my file.
I was inspired by the code given in the posts above
It works correctly for me.

toggledbits

A couple of things:

The indenting is incorrect. The parser may accept it, for now, but a future upgrade to the parser library may be more strict (I do not write the library, I just include it as a dependency). Use a tool like yamllint to fix it.
You should not change the values in the map section. The values there are meant to map Hass' values into Reactor's values, and the Reactor-side values you have modified are not valid Reactor values for the button.state attribute. Valid values are defined by Reactor's button capability and include: single, double, triple, 4, 5, hold, release, and long. You should return these to the values originally given, and adjust your condition tests accordingly.

apocalypsehobby

@toggledbits wow, thank you.

I've successfully added the Hank devices to the reactor.yaml file, along with a couple other remotes. Here are my notes for anyone else on this endeavor.

Hank HKZW-SCN04 has 4 buttons, and from my tests they do not support 2x or 3x clicks/presses.
Minoston MR40Z V1.0 has 4 buttons, and supports all of the presses that you mapped.
Zooz ZEN34 Ver. 1.0 has 2 buttons and supports all the presses that you mapped PLUS it has 4x and 5x presses as well.

apocalypsehobby

Hey friends - I'm trying this again with another remote, this time the ZB-5001 from RGB Genie.

It's not working yet, but I feel like I'm close. The device is successfully populating into MSR as an Entity, but when I press a button on the remote it does not report any changes to MSR.

Could you help me check my work?

DATA FROM HASSIO_EVENTS.LOG

"endpoint_id" tells which button has been pressed (1-5)
"cluster_id" seems to always stay at 6
"command" shows whether you've pressed the "on" or "off" side of buttons 1-5

zha_event {
	"id": 1676585189844,
	"type": "event",
	"event": {
		"event_type": "zha_event",
		"data": {
			"device_ieee": "60:a4:23:ff:fe:65:a3:fb",
			"unique_id": "60:a4:23:ff:fe:65:a3:fb:2:0x0006",
			"device_id": "516aaf4459a4f4f319a178de36a28dfd",
			"endpoint_id": 1,
			"cluster_id": 6,
			"command": "on",
			"args": [],
			"params": {}
		},
		"origin": "LOCAL",
		"time_fired": "2023-02-16T22:07:24.518489+00:00",
		"context": {
			"id": "01GSE495V6J686X0RGXYZ046CG",
			"parent_id": null,
			"user_id": null
		}
	}

MY BEST ATTEMPT AT THE CODE FOR REACTOR.YAML

      event_targets:
        "RGBG-Remote-Button-1":
          name: "RGBG Remote Button 1"
          capabilities:
            - button
          events:
            - event:
                event_type: zha_event
                data:
                  device_id: "516aaf4459a4f4f319a178de36a28dfd"
                  endpoint_id: "1"
              response:
                button.since:
                  from: event.data.time_fired
                button.state:
                  from: event.data.command
                  map:
                    on: on
                    off: off

Set Reaction > Script Action

Errors after updating to MQTTController build 25139

🎉 My very first MSR controller: OpenSprinkler

Advice reqeusted to migrate MSR from Bare Metal to Container

Reactor (Multi-System/Multi-Hub) Announcements

Can´t restart or upgrade/deploy MSR

[Solved] Limit HA Entity in MSR

Organizing/ structuring rule sets and rules

Moving MSR from a QNAP container to RP 5 - some issues

Widget deletion does not work and landing page (status) is empy

Need help reducing false positive notifications

Deleting widgets

MQTT configuration question

System Configuration Check - time is offset

Programmatically capture HTTP Request action status code or error

ZwaveJSUI - RGBWW BULB - Warm/Cold White interfered with RGB settings - Bulb doesn't change color if in WarmWhite state.

Problem with simultaneous notifications.

Problem after upgrading to 25067

Global expressions not always evaluated

[Solved] Local expression evaluation

Adding remotes, scene controllers as entities to MSR

Recent Topics
