Build 21228 has been released. Docker images available from DockerHub as usual, and bare-metal packages here.
Home Assistant up to version 2021.8.6 supported; the online version of the manual will now state the current supported versions;
Fix an error in OWMWeatherController that could cause it to stop updating;
Unify the approach to entity filtering on all hub interface classes (controllers); this works for device entities only; it may be extended to other entities later;
Improve error detail in messages for EzloController during auth phase;
Add isRuleSet() and isRuleEnabled() functions to expressions extensions;
Implement set action for lock and passage capabilities (makes them more easily scriptable in some cases);
Fix a place in the UI where 24-hour time was not being displayed.
Hi guys,
Just wondering how you guys organize your rule sets and rules. I wish I had an extra layer to have some more granularity, but my feature request was not popular.
Maybe there are better ways to organize my rule sets.
I use the rule sets now primarily for rooms. So a rule set per room. But maybe grouping by functionality works better. Any examples/ suggestions would be appreciated.
I have the following yaml configuration in local_mqtt_devices file
x_mqtt_device:
set_speed:
arguments:
speed:
type: str
topic: "command/%friendly_name%"
payload:
type: json
expr: '{ "fan": parameters.speed }'
While this works fine, I'm wondering how this could be changed to "fixed" parameters, as in this case "fan" only accepts "A", "Q" or a numeric value of 1-5?
Hi!
I get this message when I'm on the status tab:
System Configuration Check
The time on this system and on the Reactor host are significantly different. This may be due to incorrect system configuration on either or both. Please check the configuration of both systems. The host reports 2025-04-01T15:29:29.252Z; browser reports 2025-04-01T15:29:40.528Z; difference 11.276 seconds.
I have MSR installed as a docker on my Home Assistant Blue / Hardkernel ODROID-N2/N2+. MSR version is latest-25082-3c348de6.
HA versions are:
Core 2025.3.4
Supervisor 2025.03.4
Operating System 15.1
I have restarted HA as well as MSR multiple times. This message didn´t show two weeks ago. Don´t know if it have anything to do with the latest MSR version.
Do anyone know what I can try?
Thanks in advance!
Let's Be Careful Out There (Hill Street reference...)
/Fanan
I have a very strange situation, where if InfluxDB restarts, other containers may fail when restarting at the same time (under not easy to understand circumstances), and InfluxDB remains unreachable (and these containers crashes). I need to reboot these containers in an exact order, after rebooting InfluxDB.
While I understand what's going on, I need a way to reliable determine that InfluxDB is not reachable and these containers are not reachable, in order to identify this situation and manually check what's going on - and, maybe, in the future, automatically restart them if needed.
So, I was looking at HTTP Request action, but I need to capture the HTTP response code, instead of the response (becase if ping is OK, InfluxDB will reply with a 204), and, potentially, a way to programmatically detect that it's failing to get the response.
While I could write a custom HTTP controller for this or a custom HTTP virtual device, I was wondering if this is somewhat on you roadmap @toggledbits
Thanks!
Hi ,
I'm on
-Reactor (Multi-hub) latest-25067-62e21a2d
-Docker on Synology NAS
-ZWaveJSUI 9.31.0.6c80945
Problem with ZwaveJSUI:
When I try to change color to a bulb RGBWW, it doesn't change to the RGB color and the bulb remains warm or cold white.
I tryed with Zipato RGBW Bulb V2 RGBWE2, Hank Bulb HKZW-RGB01, Aentec 6 A-ZWA002, so seems that it happens with all RGBWW bulb with reactor/zwavejsui.
I'm using from reator the entity action: "rgb_color.set" and "rgb_color.set_rgb".
After I send the reactor command, It changes in zwavejsui the rgb settings but doesn't put the white channel to "0", so the prevalent channel remains warm/cold White and the bulb doesn't change into the rgb color.
This is the status of the bulb in zwavejsui after "rgb_color.set" (235,33,33,) and the bulb is still warmWhite.
x_zwave_values.Color_Switch_currentColor={"warmWhite":204,"coldWhite":0,"red":235,"green":33,"blue":33}
The "cold white" and "warm white" settings interfer with the rgb color settings.
Reactor can change bulb colors with rgb_color set — (value, ui8, 0x000000 to 0xffffff) or rgb_color set_rgb — (red, green, blue, all ui1, 0 to 255) but if warm or cold white
are not to "0", zwavejsui doesn't change them and I can't find a way to change into rgb or from rgb back to warm white.
So if I use from reactor: rgb_color set_rgb — (235,33,33) in zwavejsui I have
x_zwave_values.Color_Switch_targetColor={"red":235,"green":33,"blue":33}
14/03/2025, 16:43:57 - value updated
Arg 0:
└─commandClassName: Color Switch
└─commandClass: 51
└─property: targetColor
└─endpoint: 0
└─newValue
└──red: 235
└──green: 33
└──blue: 33
└─prevValue
└──red: 235
└──green: 33
└──blue: 33
└─propertyName: targetColor
14/03/2025, 16:43:57 - value updated
Arg 0:
└─commandClassName: Color Switch
└─commandClass: 51
└─property: currentColor
└─endpoint: 0
└─newValue
└──warmWhite: 204
└──coldWhite: 0
└──red: 235
└──green: 33
└──blue: 33
└─prevValue
└──warmWhite: 204
└──coldWhite: 0
└──red: 235
└──green: 33
└──blue: 33
└─propertyName: currentColor
In zwavejsui, the bulb changes rgb set but warm White remains to "204" and the bulb remais on warm White channel bacause is prevalent on rgb set.
x_zwave_values.Color_Switch_currentColor_0=204
x_zwave_values.Color_Switch_currentColor_1=0
x_zwave_values.Color_Switch_currentColor_2=235
x_zwave_values.Color_Switch_currentColor_3=33
x_zwave_values.Color_Switch_currentColor_4=33
Is it possible to targetColor also for "warmWhite" and "coldWhite" and have something similar to this?
x_zwave_values.Color_Switch_targetColor={"warmWhite":0,"coldWhite":0,"red":235,"green":33,"blue":33}
Thanks in advance.
MSR had been running fine, but I decided to follow the message to upgrade to 25067. Since the upgrade, I have received the message "Controller "<name>" (HubitatController hubitat2) could not be loaded at startup. Its ID is not unique." MSR throws the message on every restart. Has anyone else encountered this problem?
I am running MSR on a Raspberry Pi4 connecting to two Hubitat units over an OpenVPN tunnel. One C8 and a C8 Pro. Both are up-to-date. It appears that despite the error message that MSR may be operating properly.
I am getting a Runtime error on different browsers when I click exit when editing an existing or creating a new global reaction containing a group. If the global reaction does not have a group I don't get an error. I see a similar post on the forum about a Runtime Error when creating reactions but started a new thread as that appears to be solved.
The Runtime Error is different in the two browsers
Safari v18.3
@http://192.168.10.21:8111/reactor/en-US/lib/js/reaction-list.js:171:44
You may report this error, but do not screen shot it. Copy-paste the complete text. Remember to include a description of the operation you were performing in as much detail as possible. Report using the Reactor Bug Tracker (in your left navigation) or at the SmartHome Community.
Google Chrome 133.0.6943.142
TypeError: self.editor.isModified is not a function
at HTMLButtonElement.<anonymous> (http://192.168.10.21:8111/reactor/en-US/lib/js/reaction-list.js:171:34)
You may report this error, but do not screen shot it. Copy-paste the complete text. Remember to include a description of the operation you were performing in as much detail as possible. Report using the Reactor Bug Tracker (in your left navigation) or at the SmartHome Community.
Steps to reproduce:
Click the pencil to edit a global reaction with a group.
Click the Exit button.
Runtime error appears.
or
Click Create Reaction
Click Add Action
Select Group
Add Condition such as Entity Attribute.
Add an Action.
Click Save
Click Exit
Runtime error appears.
I don’t know how long the error has been there as I haven’t edited the global reaction in a long time.
Reactor (Multi-hub) latest-25060-f32eaa46
Docker
Mac OS: 15.3.1
Thanks
I am trying to delete a global expression (gLightDelay) but for some strange reason, it comes back despite clicking the Delete this expression and Save Changes buttons.
I have not created a global expression for some times and just noticed this while doing some clean-up.
I have upgraded Reactor to 25067 from 25060 and the behaviour is still there. I have restarted Reactor (as well as restarting its container) and cleared the browser's cache several times without success.
Here's what the log shows.
[latest-25067]2025-03-08T23:50:22.690Z <wsapi:INFO> [WSAPI]wsapi#1 rpc_echo [Object]{ "comment": "UI activity" }
[latest-25067]2025-03-08T23:50:26.254Z <GlobalExpression:NOTICE> Deleting global expression gLightDelay
[latest-25067]2025-03-08T23:50:27.887Z <wsapi:INFO> [WSAPI]wsapi#1 rpc_echo [Object]{ "comment": "UI activity" }
Reactor latest-25067-62e21a2d
Docker on Synology NAS
Morning, experts. Hard on learning about the internet check script in MSR tools, I was wondering what suggestions anyone has about a local (i.e. non-internet dependent) notification method.
This was prompted by yesterday's fun and games with my ISP.
I've got the script Cronned and working properly but short of flashing a light on and off, I'm struggling to think of a way of alerting me (ideally to my phone)
I guess I could set up a Discord server at home, but that feels like overkill for a rare occasion. Any other suggestions?
TIA
C
Hi,
I'm trying to integrate the sonos-mqtt (https://sonos2mqtt.svrooij.io/) with the MSR and it's coming along nicely so far.
But cannot wrap my head around how to define custom capabilities in MQTT templates. I need this for the TTS announcements and similarly for the notification sounds where I would pass the sound file as parameter.
So this is what I have in the local_mqtt_devices.yaml
capabilities:
x_sonos_announcement:
attributes:
actions:
speak:
arguments:
text:
type: string
volume:
type: int
delay:
type: int
And this is the template:
templates:
sonos-announcement:
capabilities:
- x_sonos_announcement
actions:
x_sonos_announcement:
speak:
topic: "sonos/cmd/speak"
payload:
expr: >
{ "text": parameters.text, "volume": parameters.volume, "delayMs": parameters.delay, "onlyWhenPlaying": false, "engine": "neural" }
type: json
So the speak action should send something like this to topic sonos/cmd/speak
{
"text": "message goes here",
"volume": 50,
"delayMs": 100,
"onlyWhenPlaying": false,
"engine": "neural"
}
At startup the MSR seems to be quite unhappy with my configuration:
reactor | [latest-25016]2025-02-09T08:19:59.029Z <MQTTController:WARN> MQTTController#mqtt entity Entity#mqtt>sonos-announcement unable to configure capabilities [Array][ "x_sonos_announcement" ]
reactor | i18n: missing fi-FI language string: Configuration for {0:q} is incomplete because the following requested capabilities are undefined: {1}
reactor | i18n: missing fi-FI language string: Configuration for {0:q} has unrecognized capability {1:q} in actions
reactor | Trace: Configuration for {0:q} is incomplete because the following requested capabilities are undefined: {1}
reactor | at _T (/opt/reactor/server/lib/i18n.js:611:28)
reactor | at AlertManager.addAlert (/opt/reactor/server/lib/AlertManager.js:125:25)
reactor | at MQTTController.sendWarning (/opt/reactor/server/lib/Controller.js:627:30)
reactor | at MQTTController.start (/var/reactor/ext/MQTTController/MQTTController.js:268:26)
reactor | at async Promise.allSettled (index 0)
Configuration for "sonos-announcement" has unrecognized capability "x_sonos_announcement" in actions
Controller: MQTTController#mqtt
Last 10:21:37 AM
Configuration for "sonos-announcement" is incomplete because the following requested capabilities are undefined: x_sonos_announcement
Controller: MQTTController#mqtt
Last 10:21:37 AM
This is probably a pretty stupid question and the approach may not even work at all, but maybe someone or @toggledbits for sure, could point me to the right direction.
Basically the idea is to be able to send TTS messages from reactions using entity actions. I've previously used HTTP requests to Sonos HTTP API (https://hub.docker.com/r/chrisns/docker-node-sonos-http-api/) for the same functionality, but since moving to sonos-mqtt, I need a way to send the TTS notifications using MQTTController. Along with the actual message, volume and delay must also be parameterizable.
br,
mgvra
MSR latest-25016-d47fea38 / MQTTController [0.2.24293]
Can´t restart or upgrade/deploy MSR
Multi-System Reactor
2
Posts
2
Posters
21
Views
2
Watching
-
I can´t upgrade MSR anymore. I run it in docker on my Home Assistant blue (odroid). I reach it in Portainer. I guess it have something to do with nodejs, after reading the docs here on the forum, but I´m not sure. I have never updated it, since I don´t even know where to start. I don´t know how to fix this. I´m not a programmer or likewise, so please explain as if your were speaking to a total newbie...
I´m on MSR ver 25097-03b6faee.
Home Assistant 2025.5.3.Thanks,
/Fanan -
I can´t upgrade MSR anymore. I run it in docker on my Home Assistant blue (odroid). I reach it in Portainer. I guess it have something to do with nodejs, after reading the docs here on the forum, but I´m not sure. I have never updated it, since I don´t even know where to start. I don´t know how to fix this. I´m not a programmer or likewise, so please explain as if your were speaking to a total newbie...
I´m on MSR ver 25097-03b6faee.
Home Assistant 2025.5.3.Thanks,
/Fanan
@Fanan said in Can´t restart or upgrade/deploy MSR:
I guess it have something to do with nodejs
Doubtful. The image provides its own nodejs, and doesn't use any version available outside the container.
Seems more like a Portainer problem to me. Was Portainer or HassOS upgraded recently?
