I'm running MSR build 25139 on Docker, using MQTT controller 24293, and everything working as expected. But if I try to upgrade to MQTTController build 25139, I'm getting the following errors on MSR UI:
An Entity Attribute condition in "Lay-Z-Spa auto heating off" (Terrace) failed because the referenced entity "Lay-Z-Spa States" (mqtt>layzspa_states) does not have attribute value_sensor.god
Last 11:20:37
An Entity Attribute condition in "Lay-Z-Spa auto heating off" (Terrace) failed because the referenced entity "Lay-Z-Spa States" (mqtt>layzspa_states) does not have attribute temperature_sensor.green
Last 11:20:37
An Entity Attribute condition in "Lay-Z-Spa filter pump auto off" (Terrace) failed because the referenced entity "Lay-Z-Spa States" (mqtt>layzspa_states) does not have attribute temperature_sensor.red
Last 11:20:37
An Entity Attribute condition in "Lay-Z-Spa filter pump auto run" (Terrace) failed because the referenced entity "Lay-Z-Spa States" (mqtt>layzspa_states) does not have attribute value_sensor.pump
Last 11:20:37
An Entity Attribute condition in "Lay-Z-Spa watchdog" (Terrace) failed because the referenced entity "Lay-Z-Spa States" (mqtt>layzspa_states) does not have attribute value_sensor.status
Last 11:20:37
My MQTT configuration (local_mqtt_devices.yaml) for the related entity is:
layzspa_message:
type: ValueSensor
capabilities: ["temperature_sensor", "value_sensor", "power_sensor"]
primary_attribute: power_sensor.value
events:
"layzspa/message":
"power_sensor.value":
json_payload: true
if_expr: '! isnull( payload?.PWR )'
expr: "float(payload.PWR)"
"value_sensor.air":
json_payload: true
if_expr: '! isnull( payload?.AIR )'
expr: "float(payload.AIR)"
"value_sensor.pump":
json_payload: true
if_expr: '! isnull( payload?.FLT )'
expr: "float(payload.FLT)"
"value_sensor.god":
json_payload: true
if_expr: '! isnull( payload?.GOD )'
expr: "float(payload.GOD)"
"value_sensor.lock":
json_payload: true
if_expr: '! isnull( payload?.LCK )'
expr: "float(payload.LCK)"
"value_sensor.unit":
json_payload: true
if_expr: '! isnull( payload?.UNT )'
expr: "float(payload.UNT)"
"value_sensor.error":
json_payload: true
if_expr: '! isnull( payload?.ERR )'
expr: "float(payload.ERR)"
"temperature_sensor.green":
json_payload: true
if_expr: '! isnull( payload?.GRN )'
expr: "float(payload.GRN)"
"temperature_sensor.red":
json_payload: true
if_expr: '! isnull( payload?.RED )'
expr: "float(payload.RED)"
"temperature_sensor.target":
json_payload: true
if_expr: '! isnull( payload?.TGT )'
expr: "float(payload.TGT)"
"temperature_sensor.value":
json_payload: true
if_expr: '! isnull( payload?.TMP )'
expr: "float(payload.TMP)"
"temperature_sensor.virtual":
json_payload: true
if_expr: '! isnull( payload?.VTM )'
expr: "round(float(payload.VTM), 1)"
"temperature_sensor.ambient":
json_payload: true
if_expr: '! isnull( payload?.AMB )'
expr: "float(payload.AMB)"
"layzspa/Status":
"value_sensor.status":
if_expr: '! isnull( payload )'
expr: "payload"
"layzspa/button":
"value_sensor.button":
if_expr: '! isnull( payload )'
expr: "payload"
and in reactor.yaml I have:
"layzspa_states":
name: "Lay-Z-Spa States"
friendly_name: 'Lay-Z-Spa States'
include: layzspa_message
I realize my MQTT configuration might be a bit unorthodox, but could there still be something unintentional in the latest MQTTController build? If needed, I can provide detailed logs.
Since today is my birthday - and I still pretend to be unconventional - I'm giving away a present to this wonderful community and I'm releasing my first OpenSprinkler controller for MSR. It was real fun to code it - and while it's still WIP, it seems to work OK for me. It's polling-based at the moment, but I'll add support for updates via MQTT very soon (it's already partially coded).
Get it at (install is similar to MQTTController and such):
https://github.com/dbochicchio/reactor-opensprinkler
Feel free to try it. It's beta software, but it's stable. I'll update it weekly until all the tasks from my todo list are empty.
Since I've learnt a lot from this controller, I'll explore new controllers soon.
Good day all,
I'm in the process of trying to shut down my 10 year old Linux home server that served many purposes, but primarily it's what I used for my NAS/Plex Media server. I migrated the NAS aspect of the server in November of last year to a true NAS solution (Ubiquti UNAS Pro), which is rack mount and much more efficient than my old tower, which it's only side benefit was heating my home office during the winter. Unfortunately it also means heating my home office during the summer, which were about to be in full swing.
I have two things running on this 10 year old server at this point. MSR and pi-hole. I'm running Plex Media Server on Fedora Workstation in Podman on mini PC, which is much more energy efficient than my old tower. My next step is to migrate MSR. I know there are images of MSR out there, and creating it is well documented. I'm going to be using Podman instead of Docker for various reasons, but they work very similar. What I don't know, is what I need to do to migrate my existing Bare Metal installation over to a container.
Has anyone done this? Any advice?
Build 21228 has been released. Docker images available from DockerHub as usual, and bare-metal packages here.
Home Assistant up to version 2021.8.6 supported; the online version of the manual will now state the current supported versions;
Fix an error in OWMWeatherController that could cause it to stop updating;
Unify the approach to entity filtering on all hub interface classes (controllers); this works for device entities only; it may be extended to other entities later;
Improve error detail in messages for EzloController during auth phase;
Add isRuleSet() and isRuleEnabled() functions to expressions extensions;
Implement set action for lock and passage capabilities (makes them more easily scriptable in some cases);
Fix a place in the UI where 24-hour time was not being displayed.
Hi guys,
Just wondering how you guys organize your rule sets and rules. I wish I had an extra layer to have some more granularity, but my feature request was not popular.
Maybe there are better ways to organize my rule sets.
I use the rule sets now primarily for rooms. So a rule set per room. But maybe grouping by functionality works better. Any examples/ suggestions would be appreciated.
I have the following yaml configuration in local_mqtt_devices file
x_mqtt_device:
set_speed:
arguments:
speed:
type: str
topic: "command/%friendly_name%"
payload:
type: json
expr: '{ "fan": parameters.speed }'
While this works fine, I'm wondering how this could be changed to "fixed" parameters, as in this case "fan" only accepts "A", "Q" or a numeric value of 1-5?
Hi!
I get this message when I'm on the status tab:
System Configuration Check
The time on this system and on the Reactor host are significantly different. This may be due to incorrect system configuration on either or both. Please check the configuration of both systems. The host reports 2025-04-01T15:29:29.252Z; browser reports 2025-04-01T15:29:40.528Z; difference 11.276 seconds.
I have MSR installed as a docker on my Home Assistant Blue / Hardkernel ODROID-N2/N2+. MSR version is latest-25082-3c348de6.
HA versions are:
Core 2025.3.4
Supervisor 2025.03.4
Operating System 15.1
I have restarted HA as well as MSR multiple times. This message didn´t show two weeks ago. Don´t know if it have anything to do with the latest MSR version.
Do anyone know what I can try?
Thanks in advance!
Let's Be Careful Out There (Hill Street reference...)
/Fanan
I have a very strange situation, where if InfluxDB restarts, other containers may fail when restarting at the same time (under not easy to understand circumstances), and InfluxDB remains unreachable (and these containers crashes). I need to reboot these containers in an exact order, after rebooting InfluxDB.
While I understand what's going on, I need a way to reliable determine that InfluxDB is not reachable and these containers are not reachable, in order to identify this situation and manually check what's going on - and, maybe, in the future, automatically restart them if needed.
So, I was looking at HTTP Request action, but I need to capture the HTTP response code, instead of the response (becase if ping is OK, InfluxDB will reply with a 204), and, potentially, a way to programmatically detect that it's failing to get the response.
While I could write a custom HTTP controller for this or a custom HTTP virtual device, I was wondering if this is somewhat on you roadmap @toggledbits
Thanks!
Hi ,
I'm on
-Reactor (Multi-hub) latest-25067-62e21a2d
-Docker on Synology NAS
-ZWaveJSUI 9.31.0.6c80945
Problem with ZwaveJSUI:
When I try to change color to a bulb RGBWW, it doesn't change to the RGB color and the bulb remains warm or cold white.
I tryed with Zipato RGBW Bulb V2 RGBWE2, Hank Bulb HKZW-RGB01, Aentec 6 A-ZWA002, so seems that it happens with all RGBWW bulb with reactor/zwavejsui.
I'm using from reator the entity action: "rgb_color.set" and "rgb_color.set_rgb".
After I send the reactor command, It changes in zwavejsui the rgb settings but doesn't put the white channel to "0", so the prevalent channel remains warm/cold White and the bulb doesn't change into the rgb color.
This is the status of the bulb in zwavejsui after "rgb_color.set" (235,33,33,) and the bulb is still warmWhite.
x_zwave_values.Color_Switch_currentColor={"warmWhite":204,"coldWhite":0,"red":235,"green":33,"blue":33}
The "cold white" and "warm white" settings interfer with the rgb color settings.
Reactor can change bulb colors with rgb_color set — (value, ui8, 0x000000 to 0xffffff) or rgb_color set_rgb — (red, green, blue, all ui1, 0 to 255) but if warm or cold white
are not to "0", zwavejsui doesn't change them and I can't find a way to change into rgb or from rgb back to warm white.
So if I use from reactor: rgb_color set_rgb — (235,33,33) in zwavejsui I have
x_zwave_values.Color_Switch_targetColor={"red":235,"green":33,"blue":33}
14/03/2025, 16:43:57 - value updated
Arg 0:
└─commandClassName: Color Switch
└─commandClass: 51
└─property: targetColor
└─endpoint: 0
└─newValue
└──red: 235
└──green: 33
└──blue: 33
└─prevValue
└──red: 235
└──green: 33
└──blue: 33
└─propertyName: targetColor
14/03/2025, 16:43:57 - value updated
Arg 0:
└─commandClassName: Color Switch
└─commandClass: 51
└─property: currentColor
└─endpoint: 0
└─newValue
└──warmWhite: 204
└──coldWhite: 0
└──red: 235
└──green: 33
└──blue: 33
└─prevValue
└──warmWhite: 204
└──coldWhite: 0
└──red: 235
└──green: 33
└──blue: 33
└─propertyName: currentColor
In zwavejsui, the bulb changes rgb set but warm White remains to "204" and the bulb remais on warm White channel bacause is prevalent on rgb set.
x_zwave_values.Color_Switch_currentColor_0=204
x_zwave_values.Color_Switch_currentColor_1=0
x_zwave_values.Color_Switch_currentColor_2=235
x_zwave_values.Color_Switch_currentColor_3=33
x_zwave_values.Color_Switch_currentColor_4=33
Is it possible to targetColor also for "warmWhite" and "coldWhite" and have something similar to this?
x_zwave_values.Color_Switch_targetColor={"warmWhite":0,"coldWhite":0,"red":235,"green":33,"blue":33}
Thanks in advance.
MSR had been running fine, but I decided to follow the message to upgrade to 25067. Since the upgrade, I have received the message "Controller "<name>" (HubitatController hubitat2) could not be loaded at startup. Its ID is not unique." MSR throws the message on every restart. Has anyone else encountered this problem?
I am running MSR on a Raspberry Pi4 connecting to two Hubitat units over an OpenVPN tunnel. One C8 and a C8 Pro. Both are up-to-date. It appears that despite the error message that MSR may be operating properly.
Expressions in MQTT Payload?
-
I'm trying to send a video overlay to BlueIris. BI is receving my MQTT Message and it is writing it to a Macro but it doesnt appear that I can use expressions in MQTT Payloads with Reactor?
Output from BlueIris (no expression data):
I figured a workaround by using HTTP GET but I just wondered if I am doing something wrong with getting expression variables to work with MQTT.
This works with BlueIris:
BlueIris returns actual expression data:
-
OK I dont know what happened. I tried it again and it worked??? SMH...
-
@therealdb I want to caution on the words "the correct way"... the payload of an MQTT message is just a byte stream... it's a string. It is not required to be JSON, as you show here, and in fact in this topic's case, it is whatever BlueIris defines it to be. I don't know what works for BlueIris, be it JSON or the string OP builds here or something else entirely. But I wouldn't say that your response is the "correct way" because that depends entirely on what BlueIris defines the payload to be.
Edit: documentation is a bit hard to find for this part of BlueIris, at least for my "just woke up completely uncaffeinated" brain, but I tested OP's payload string with my own BlueIris and it works, so it's definitely not JSON, they're just using the URL parameter form as the payload (lazy coding, but it works).
Author of Multi-system Reactor and Reactor, DelayLight, Switchboard, and about a dozen other plugins that run on Vera and openLuup.
-
@therealdb I want to caution on the words "the correct way"... the payload of an MQTT message is just a byte stream... it's a string. It is not required to be JSON, as you show here, and in fact in this topic's case, it is whatever BlueIris defines it to be. I don't know what works for BlueIris, be it JSON or the string OP builds here or something else entirely. But I wouldn't say that your response is the "correct way" because that depends entirely on what BlueIris defines the payload to be.
Edit: documentation is a bit hard to find for this part of BlueIris, at least for my "just woke up completely uncaffeinated" brain, but I tested OP's payload string with my own BlueIris and it works, so it's definitely not JSON, they're just using the URL parameter form as the payload (lazy coding, but it works).
@toggled-bits yes, you’re right regarding JSON. I was referring to the syntax to concatenate variables and constant text.
I’m not a blue iris expert and I’ll prefer mqtt anytime, since the retry logic is attached to the qos, whereas you’ll need to write a while block to retry in case of error when using http requests. -
